——————————————————————————————————— Hairui edge milling machine are known worldwide for their excellent milling quality.
Servo power head model, high-speed power head model or double power head model is optional to further improve the milling efficiency.
If have higher requirements, can choose the CNC model.
HRXB-edge milling machine is the special equipment for milling steel plates in the metal processing industry, which adopts integrated bed structure with compact and beautiful appearance. The steel plate is placed on the worktable, and after the positioning is accurate, the steel plate is pressed by the hydraulic cylinder, the position and angle of the milling power head are adjusted and the relevant milling parameters are set, and then the milling process is carried out. The standard cutter and the forming cutter are interchangeable, and can process the beveled edge, straight edge, U-shaped groove and so on of various steel plates, the milling speed is stepless adjustable by frequency conversion, and it can return quickly after milling. The equipment has the advantages of advanced structure, stable and reliable operation, high degree of automation, convenient operation and so on.
The standard model is ordinary single power head model, and servo power head model, high-speed power head model or double power head model is optional to further improve the milling efficiency. If have higher requirements, can choose the CNC model.
|
Model |
HRXB-4000 |
HRXB-6000 |
HRXB-9000 |
HRXB-12000 |
|
Steel Plate Thickness |
6-100mm |
|||
|
Milling Angle |
0-45° |
|||
|
Milling Feed Speed |
50-500mm/min |
100-1000mm/min |
||
|
Milling Return Speed |
2000mm/min |
|||
|
Horizontal Milling Feed Motor Power |
2.2kw |
3kw |
||
|
Vertical Adjustment Motor Power |
0.55kw |
|||
|
Milling Spindle Speed |
75/105/145/215/300/420rpm |
|||
|
Milling Spindle Motor Power |
7.5kw |
|||
|
Milling Cutter Diameter |
125/160/200/250/315mm |
|||
|
Hydraulic Station Motor Power |
5.5kw |
|||
|
IP Grade |
IP54 |
|||
|
Input Power Supply |
3×380/400/415V, 50/60Hz |
|||
|
Equipment Main Color |
RAL 5015 Himmelblau or Customized |
|||
According to the actual needs of customers, provide corresponding technical guidance and equipment information, answer various questions raised by customers, design laser processing solutions for customers from technical feasibility, and provide related equipment for customers to visit, sample, test machine.
Sales Service
Investigate the customer’s machine use site, assist the user in planning the layout of the water, electricity, gas and other equipment in the production site according to the actual situation on site, provide the customer with a complete set of equipment operation instructions, and provide training service for the user’s equipment operator. Before delivery, train the user's equipment operators on basic equipment theory, safety protection and equipment maintenance.
After Sales Service
In the user’s factory, the user’s equipment operator is trained in actual processing operations, equipment daily maintenance and safe operation to ensure that the user can familiarize with the equipment operation rules and methods as soon as possible, and can independently use the equipment for production. After the complete set of equipment is installed and debugged at the user’s site, the warranty is free for one year from the date of acceptance by the user. Our company will also arrange technical personnel to conduct technical visits from time to time, communicate with customers on routine maintenance and inspection of equipment, and answer various questions raised by users.
Service Commitment
Service response time within 2 hours, the professional after-sales service team provides 24-hour technical support by email, video, telephone and other communication methods to provide customers with timely, comprehensive, convenient and efficient technical services.
-
