——————————————————————————————————— Hairui rib plate assembling machine are known worldwide for their excellent quality.
HRGZ-rib plate assembling machine is the special equipment for steel structure manufacturers to assembling and welding box beam rib plate. First overturning the worktable to horizontal position, hoisting rib plate to be assembled on the worktable, adjust the position of the positioning baffle and the pressing mechanism according to the size of the rib plate to be assembled, then press the workpiece through the air cylinder, overturning the worktable to suitable welding angle, and welding the front side, after welding the front side, continue to overturning the worktable to suitable welding angle and then welding the back side, after welding completed, overturning the worktable to horizontal position, release the air cylinder and unloading the assembled and welded workpiece. The equipment has the advantages of advanced structure, stable and reliable operation, high degree of automation, convenient operation and so on.
|
Model |
HRGZ-12/15 |
||
|
Rib Plate Size |
250-1200/1500mm |
Rib Plate Thickness |
≤80mm |
|
Load Capacity |
1500kg |
Overturning Angle |
±180° |
|
Overturning Speed |
1.5rpm |
Overturning Motor Power |
0.75kw |
|
IP Grade |
IP54 |
||
|
Input Power Supply |
3×380/400/415V, 50/60Hz |
||
|
Equipment Main Color |
RAL 5015 Himmelblau or Customized |
||
According to the actual needs of customers, provide corresponding technical guidance and equipment information, answer various questions raised by customers, design laser processing solutions for customers from technical feasibility, and provide related equipment for customers to visit, sample, test machine.
Sales Service
Investigate the customer’s machine use site, assist the user in planning the layout of the water, electricity, gas and other equipment in the production site according to the actual situation on site, provide the customer with a complete set of equipment operation instructions, and provide training service for the user’s equipment operator. Before delivery, train the user's equipment operators on basic equipment theory, safety protection and equipment maintenance.
After Sales Service
In the user’s factory, the user’s equipment operator is trained in actual processing operations, equipment daily maintenance and safe operation to ensure that the user can familiarize with the equipment operation rules and methods as soon as possible, and can independently use the equipment for production. After the complete set of equipment is installed and debugged at the user’s site, the warranty is free for one year from the date of acceptance by the user. Our company will also arrange technical personnel to conduct technical visits from time to time, communicate with customers on routine maintenance and inspection of equipment, and answer various questions raised by users.
Service Commitment
Service response time within 2 hours, the professional after-sales service team provides 24-hour technical support by email, video, telephone and other communication methods to provide customers with timely, comprehensive, convenient and efficient technical services.
-
