——————————————————————————————————— Hairui gantry CNC flame & plasma multi-head strip cutting machine are known worldwide for their excellent quality.
Multiple sets of straight flame cutting torches meet the cutting needs of strip plates, and in addition, the electric lifting function of the straight flame cutting torch beam is optional.
HRGS-gantry CNC flame & plasma multi-head strip cutting machine is mainly used for steel structure manufacturers to cut various steel plates. Equipped with both CNC flame cutting torch, CNC plasma cutting torch and straight flame cutting torch, which can meet the cutting needs of strip plates and various special-shaped plates at the same time. The standard model is fixed structure of the straight flame cutting torch beam, and the electric lifting function of the straight flame cutting torch beam is optional, which avoids the separate height adjustment of each set of straight flame cutting torch and significantly improves the production efficiency.
This product can be customized by choosing different guide rail center distance, guide rail length and different number of cutting torches according to actual needs. In addition, double flame cutting torch, triple flame cutting torch, powder spraying & marking device, automatic height controller and drilling device are optional to meet diversified production needs.
|
Guide Rail Center Distance |
3000-12000mm |
Effective Cutting Width |
Guide Rail Center Distance-800mm |
|
Guide Rail Length |
Customized |
Effective Cutting Length |
Guide Rail Length-2000mm |
|
Flame Cutting Speed |
50-1000mm/min |
CNC Flame Cutting Thickness |
≤300mm |
|
Plasma |
Optional |
Straight Flame Cutting Thickness |
≤100mm |
|
Quickly Positioning Speed |
6000mm/min |
Longitudinal Drive Mode |
Servo Bilateral Drive |
|
IP Grade |
IP54 |
||
|
Input Power Supply |
3×380/400/415V, 50/60Hz |
||
|
Equipment Main Color |
RAL 5015 Himmelblau or Customized |
||
According to the actual needs of customers, provide corresponding technical guidance and equipment information, answer various questions raised by customers, design laser processing solutions for customers from technical feasibility, and provide related equipment for customers to visit, sample, test machine.
Sales Service
Investigate the customer’s machine use site, assist the user in planning the layout of the water, electricity, gas and other equipment in the production site according to the actual situation on site, provide the customer with a complete set of equipment operation instructions, and provide training service for the user’s equipment operator. Before delivery, train the user's equipment operators on basic equipment theory, safety protection and equipment maintenance.
After Sales Service
In the user’s factory, the user’s equipment operator is trained in actual processing operations, equipment daily maintenance and safe operation to ensure that the user can familiarize with the equipment operation rules and methods as soon as possible, and can independently use the equipment for production. After the complete set of equipment is installed and debugged at the user’s site, the warranty is free for one year from the date of acceptance by the user. Our company will also arrange technical personnel to conduct technical visits from time to time, communicate with customers on routine maintenance and inspection of equipment, and answer various questions raised by users.
Service Commitment
Service response time within 2 hours, the professional after-sales service team provides 24-hour technical support by email, video, telephone and other communication methods to provide customers with timely, comprehensive, convenient and efficient technical services.
-
